Siemens X4i placement machine

2023-09-21
7214
Siemens X4i placement machine

Detailed introduction

Siemens placement machine X4i,siemens SIPLAcE X4i placement machine


Detailed introduction of Siemens placement machine X4i:

PCB size: 450×535mm

Placement speed: 0.026

SMT accuracy: ±0.041mm

Patch stations: 148/180

Placement speed:

Speed theory: 135,000 components/hour

IPC9850 standard: 102,000 components/hour


Siemens SMT machine X4i is mainly used in the SMT production of MID, smartphone motherboards, smart digital electronics, and consumer products.


Siemens X4i placement machine features:


(1) Highly modular to meet various needs

SIPLACE X series placement machines can handle different products with their superior characteristics and IRF3205PBF's wide component placement range to meet the different needs of customer production. SIPLACE X series placement machines support high-precision and ultra-high-speed 20-nozzle collection and placement heads.

Starting from software version 703.xx, all X-series placement machines are equipped with the newly developed SIPLACE MultiStar placement head. MultiStar placement head (CPP head for short) has higher placement speed and flexibility.


(2) SIPLACE four-track transmission system

The four-track conveyor system allows four different products to be produced simultaneously on one line. It can be configured for single, dual or four-rail use via software. The SIPLACE four-track transmission system can be configured in SIPLACE X4i and SIPLACE X4


(3) 01005 placement function

   As standard, the SIPLACE X series is designed for 01005 components and also offers nozzles developed for 01005 components. 01005 components can be mounted independently next to large components with minimum spacing.

Siemens placement machine X4i and Siemens X series placement machine, please call us for more information.
